Series Zoom Solar Floodlights for Sports Lighting Solution

Series Zoom solar floodlights use high-performance floodlights as light sources and have excellent lumen/watt ratio. With reasonable light distribution, it is suitable for different outdoor areas, such as squares, parking lots, rural roads and intersections, etc. The system uses high-efficiency monocrystalline solar modules and MPPT controllers, making the light energy conversion efficiency extremely high. In addition, the lithium iron phosphate battery used in the system has a long life. At ZGSM, you can also customize solutions for your solar floodlights, such as customized solar panels, battery capacity, dimming curves, microwave settings, etc. to meet specific project requirements. These make it a high-performance and ideal choice for off-grid solar lighting.

  • Wide power range: 20W~150W
  • High Lumen output up to 170lm/w
  • Monocrystalline silicon solar panels
  • Smart MPPT controller realizes intelligent control of lamps
  • High end battery improves the reliability of the luminaire
  • Capacity of panels and batteries can be customized
  • Long lifespan with L70>100000hrs
  • Multiple lighting control options are available, e.g. photocell, timer dimming.
  • 12 light distributions for options
Contact Us

  • ZGSM products are designed for the global market. Please contact our sales team for certification details.
  • Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.
Solar Floodlights
Solar Floodlights
Series No Zoom Series Solar Floodlights
Power 20W, 30W, 40W, 50W, 60W, 80W, 100W, 120W, 150W
Efficacy 140-170lm/W
Input Voltage DC 12/24V
Battery Spec LiFePO4 lithium 230WH-1843WH or customized
Solar Panel Spec Monocrystalline silicon 50-400W or customized
IP Rating IP66
IK Rating IK10
Beam Angle 25°, 60°, 90°, 120° or Asymmetrical
Mounting Option Bracket mounted
Solar Floodlights
Solar Floodlights
Specification_Series_Zoom Solar Floodlights

With reasonable design, solar floodlights can continue to illuminate throughout the night, reaching 8-12 hours of lighting time. Even if bad weather prevents the battery from charging the next day, it will still be able to continue providing light the second night. This is because we will take this situation into consideration during the design stage and design the battery capacity to be enough for the lamp to be used continuously for 2-3 nights. Of course, this solution will inevitably lead to an increase in the cost of solar floodlights.

While solar lights have the advantage of being energy efficient, there are some potential disadvantages to consider:

Initial investment: The upfront cost of solar floodlights is usually 4-8 times that of ordinary floodlights, which will limit their use to a certain extent.
Illumination intensity: Solar floodlights usually need to consider the cost of solar panels and batteries, so their power is often smaller, resulting in that the illumination intensity is not as high as ordinary floodlights during application.
Weather effects: In extreme weather conditions, such as heavy snow, continuous rainfall, and low temperatures, the performance of solar floodlights is often affected.

Regional restrictions: Low light intensity, covered areas(sunshine is blocked), etc. are not suitable for use with solar floodlights

The short answer is – it depends. Whether sunlight is enough to charge a solar floodlight depends on various factors, such as the intensity and duration of sunlight, the efficiency of the solar panel and the capacity of the battery.

If the solar panel has a low power and the battery capacity is large, then there will not be enough sunlight in a day to fully charge the entire battery.
On the contrary, if the power of the solar panel is large and the battery capacity is small, then 2-3 hours of sunlight during the day is enough to charge the entire battery.

In most cases, the power of the solar panel and the battery capacity are matched, that is, the day's sunlight just or roughly fills the battery.

Things you need to know about Solar Flood Lights

As a professional solar flood lights manufacturer, we can provide different types and functions of solar flood lights, such as wind solar hybrid flood light, AC/DC hybrid solar flood light, motion sensor solar floodlights, human body induction control solar flood lights, timer dimming solar flood lights, etc. Additional accessories for solar flood lighting systems such as foundation cages, flood lighting poles, cables, etc. are available. These solar flood lights can be widely used as sport area lighting, road lighting, school campus, etc.

Power (W)Lumens (LM)Replacement (W)Install height (M)
20W3400LM35W HPS or MH3-4m
30W5100LM60W HPS or MH4-5m
40W6800LM100W HPS or MH5-6m
50W8500LM150W HPS or MH6-7m
60W10200LM150W HPS or MH7-8m
80W13600LM200W HPS or MH8-10m
100W17000LM250W HPS or MH9-11m
120W20400LM250W HPS or MH10-12m
150W25500LM400W HPS or MH11-14m
Lead-acid Battery

Lead-acid Battery

Lead-acid batteries include electrolyte-type lead-acid batteries (VRLA) and colloidal lead-acid batteries (Gel). They are mainly used in split-type solar street lamp systems and are usually buried underground. They're bigger and cheaper, but they use fewer cycles than lithium-ion batteries.Most lead-acid batteries are 12V or 24V systems.

Lithium batteries

Lithium Battery

Majority of lithium batteries used in solar street lighting systems are ternary lithium batteries and lithium iron phosphate batteries ( LiFePo4). Lithium batteries are more costly and have a longer lifespan than lead-acid batteries.
Ternary lithium batteries provide superior cold resistance compared to lithium iron phosphate batteries. The high-temperature resistance of lithium iron phosphate batteries is better than that of ternary lithium batteries. Consequently, solar street lighting systems in high-temperature regions often use lithium iron phosphate batteries.
Available Li battery voltages for the solar street light system include 3.7V, 3.2V, 6.4V, 11.1V, and 12.8V.

MONO SOLAR PANELS

Monocrystalline Solar Panel

The photoelectric conversion efficiency of monocrystalline silicon solar panels is between 18 and 24 percent, with an average of 18 percent. This kind of solar cell has the greatest photoelectric conversion efficiency of all sorts and a lifespan of up to 25 years. However, manufacturing costs are more than for other types.

POLY SOLAR PANELS

Polycrystalline Solar Panel

The manufacturing method of polycrystalline silicon solar panels is same as monocrystalline silicon solar panels, however the photoelectric conversion efficiency of polycrystalline silicon solar panels is lower than monocrystalline silicon solar panels, it is around 16%. But it is cheaper than the monocrystalline silicon solar panels.

pwm solar controller

PWM Solar Controller

PWM solar controller is the second-generation technology, and the most on the market now. The working method is PWM control. Compared with ordinary solar controllers, it has improved a lot and can solve the problem of battery dissatisfaction. The charging conversion efficiency is 70%, But the solar panels are not fully utilized.

MPPT solar controller

MPPT Solar Controller

MPPT solar controller is a technology of the third generation. It relates to the feature "Maximum PowerPoint Tracking."It is an upgraded product of the PWM solar controller. The MPPT solar controller can detect and maintain track of the voltage and current of the solar panel in real time. Maximum power (P=U*I), ensuring that the battery is always charged with maximum power. The MPPT tracking efficiency is 99%, the system's overall power production efficiency is 97%, and the battery will have a good management.

Application

Recreational sports
Billboard lighting
Accent lighting
Parking lots
Roundabout
Outdoor sports

Do you want to customize a solar flood light system? Use the form to reach out and we will be in touch with you as quickly as possible.

Why Choose Solar Led Flood Lights?

The solar flood light is a new type of flood lighting fixture. During the day, monocrystalline or polycrystalline silicon solar panels convert solar sun energy into electricity, which is stored in maintenance-free valve-sealed batteries or lithium batteries through the solar controller, and at night, the solar controller controls the discharge of the batteries for the LED lights to work. It will bring many benefits.

  • Energy saving

Convert solar energy into electricity to drive LED flood lamps to work. Solar energy is inexhaustible.

  • Safety

Solar flood lights are powered by 12-36V solar panels, which are within the safe voltage range and will not cause electric shock accidents to people, making them safer to use.

  • Flexible application

Off-grid solar flood lights do not require a grid power supply and can operate autonomously as long as there is sunlight, which is very flexible, so they can use even in remote power-deficient areas.

  • Less investment

The solar flood light system not need power supply equipment, can be completely automated operation, no need for personnel management, so low operation, and maintenance costs.
