Home - LED Products - Solar Street Light

Solar Street Light

A solar street lamp system is a lighting system for the illumination of streets, roads, squares, and common public areas. It uses the sun’s light to work. solar powered street light is the complete set of Solar Panel, Lithium Battery, Light, Charge Controller & Poles. There are two designs split solar street light and integrated solar street light.


Series PV Split Type Solar Street Led Light

PV solar street led light is the general name of split solar street light, which can use any existing street light head of ZGSM. PV series solar panel street light adopts high quality and efficiency solar panels (more than 20%) and combines the stable performance and long-life battery and high-efficiency MPPT solar charge controller which built-in LED driver. Excellent Philips chips make the lamp efficacy up to 165lm/w. as the solar street light manufacturer, ZGSM has more than 16 years of professional in the configuration of the solar street lighting system.

Read More

Series PV3 All in One Solar Street Light

Series PV3 all in one solar street light adopts integrated design, the solar panel, lithium battery, controller, LED lamp integrated into one part, greatly convenient for customers to install. The whole lighting effect of PV3 Solar Street Light is 200 lm/ W, high light effect can guarantee the same lighting effect under the premise of greatly reducing the system configuration, thus reducing the cost. The matching monocrystalline silicon panel has a conversion efficiency of 23%, and the lithium battery can meet more than 2,000 cycles of charge and discharge. It is the best choice for lighting in remote areas.

Read More

Series N Solar Powered Street Lights

N Series Solar LED street lights are using the Latest N Series High efficacy LED street lamp, providing excellent lumen output, long-lasting stability, and splendid sight. N series solar street led light combined with Lithium battery and Mono Solar Panels to ensure the long life and high efficacy of the solar street light system. Provide 3 years warranty on the whole solar street lighting system.

Read More

Series PV4 Integrated Solar Street Light

PV4 is a new private design Integrated LED solar street light with very competitive price, with a slim design and higher conversion efficiency Mono-crystalline photovoltaic Solar panel, 200lm/w efficiency to make the products with better advantages to meet different requirements from customers, support vertical, horizontal or wall mounted.

Read More

Best Solar Street Light Manufacturer Factory, Supplier In China

ZGSM is the top manufacturer, factory, supplier of solar street lights in china since 2005. We can help you win the bidding or markets by the following point:
Highest quality
All of the materials will be top quality such as Longlife time LiFePo4 battery, high efficiency MPPT Controller, high conversion Mono solar panel, etc.
Custionized service
According to the sunshine conditions of your city, working time, regular weather, our technical team will customize a solar street light system that meets the local for you.

aging test for led lights
Aging test

Why Choose us as your Solar Powered Street Light Supplier in China?

OEM/ODM/SKD

Available to do OEM/ODM/SKD for all solar street light. No MOQ limits for solar lights retailers, wholesalers, and engineering companies.

FAST DELIVERY TIME

As a reliable solar power street light supplier, we have materials stocks for solar street lamp, regular delivery time is 3 days for samples and 2 weeks for bulk.

BEST QUALITY&PRICE

We use top stable quality solar panels and lithium battery and MPPT controller for all solar led street light. Providing 3 Years warranty at the cheapest price.

CUSTOMIZATION

We can customize power of LED street lamp and solar panel, battery capacity, controller, cables, pole, mounted bracket according to customers’ needs.

Things you need to know about Solar Street Lights

As a professional solar street light manufacturer, we can provide different types and functions of solar street lights, such as wind solar hybrid street light, AC/DC hybrid solar street light, motion sensor solar street lights, human body induction control solar street lights, timer dimming solar street lights, etc. . Additional accessories for solar street lighting systems such as foundation cages, street lighting poles, cables, etc. are available. These solar street lights can be widely used as garden lighting, road lighting, school campus, etc.

  • Types
  • Power
  • Battery
  • Solar Panel
  • Solar Controller
  • Installation
  • Application
  • Customization
solar street light

All in one solar street light

All in one solar street lights also called “Integrated solar street lights”, is a combination of high-efficiency solar panel, lithium battery, LED modules and smart controller, PIR or Motion sensor, etc. Easy to install and transport

solar street light

Split solar street lights

Split solar street light is divided into complete split and All in two types.
Complete split: Each parts are seperately.
All in two: Lithium battery and controller is build-in the LED street lamp body, the solar panels are seperately.

Power (W)Lumens (LM)Replacement (W)Install height (M)
10W2000LM35W HPS or MH3-4m
20W4000LM60W HPS or MH4-5m
30W4800LM100W HPS or MH5-6m
40W6400LM150W HPS or MH6-7m
50W9000LM150W HPS or MH7-8m
60W9600LM200W HPS or MH8-10m
80W12800LM250W HPS or MH9-11m
100W16000LM250W HPS or MH10-12m
120W19200LM400W HPS or MH11-14m
Lead-acid Battery

Lead-acid Battery

Lead-acid batteries include electrolyte-type lead-acid batteries (VRLA) and colloidal lead-acid batteries (Gel). They are mainly used in split-type solar street lamp systems and are usually buried underground. They’re bigger and cheaper, but they use fewer cycles than lithium-ion batteries.Most lead-acid batteries are 12V or 24V systems.

Lithium batteries

Lithium Battery

Majority of lithium batteries used in solar street lighting systems are ternary lithium batteries and lithium iron phosphate batteries ( LiFePo4). Lithium batteries are more costly and have a longer lifespan than lead-acid batteries.
Ternary lithium batteries provide superior cold resistance compared to lithium iron phosphate batteries. The high-temperature resistance of lithium iron phosphate batteries is better than that of ternary lithium batteries. Consequently, solar street lighting systems in high-temperature regions often use lithium iron phosphate batteries.
Available Li battery voltages for the solar street light system include 3.7V, 3.2V, 6.4V, 11.1V, and 12.8V.

MONO SOLAR PANELS

Monocrystalline Solar Panel

The photoelectric conversion efficiency of monocrystalline silicon solar panels is between 18 and 24 percent, with an average of 18 percent. This kind of solar cell has the greatest photoelectric conversion efficiency of all sorts and a lifespan of up to 25 years. However, manufacturing costs are more than for other types.

POLY SOLAR PANELS

Polycrystalline Solar Panel

The manufacturing method of polycrystalline silicon solar panels is same as monocrystalline silicon solar panels, however the photoelectric conversion efficiency of polycrystalline silicon solar panels is lower than monocrystalline silicon solar panels, it is around 16%. But it is cheaper than the monocrystalline silicon solar panels.

pwm solar controller

PWM Solar Controller

PWM solar controller is the second-generation technology, and the most on the market now. The working method is PWM control. Compared with ordinary solar controllers, it has improved a lot and can solve the problem of battery dissatisfaction. The charging conversion efficiency is 70%, But the solar panels are not fully utilized.

MPPT solar controller

MPPT Solar Controller

MPPT solar controller is a technology of the third generation. It relates to the feature “Maximum PowerPoint Tracking.”It is an upgraded product of the PWM solar controller. The MPPT solar controller can detect and maintain track of the voltage and current of the solar panel in real time. Maximum power (P=U*I), ensuring that the battery is always charged with maximum power. The MPPT tracking efficiency is 99%, the system’s overall power production efficiency is 97%, and the battery will have a good management.

Let’s take PV4 series solar powered street light as a example

side entry

Side Entry Mounted

STEP 1: Loosen the four screws on the bracket, and put the hoop anchor on the top of the bracket, fix with screws but do not screw them all, as shown above.
STEP 2: Insert the lamp into the pole according to the arrow direction, as shown above.
STEP 3: Tighten the four screws of the bracket, The installation is completed.

post top mounted

Post Top Mounted

STEP 1: Loosen the four screws on the bracket, but do not unscrew them all, as shown above.
STEP 2: Insert the lamp into the pole according to the arrow direction, as shown above.
STEP 3: Tighten the four screws of the bracket, The installation is completed.

wall mounted

Wall Mounted

STEP 1: Loosen the four screws on the bracket, remove the hoop anchor.
STEP 2: Drill four M8 holes on the wall refer to mounted bracket holes.
STEP 4: Fix the lamp to the wall using fours M8*60 expansion screws, the installation is completed.

Application

Roadway lighting
Paths way lighting
Garden lighting
Driveway lighting
Parking lots lighting

Do you want to customize a solar street light system? Use the form to reach out and we will be in touch with you as quickly as possible.

Why Choose Solar Led Street Lights?

The solar street light is a new type of road lighting fixture. During the day, monocrystalline or polycrystalline silicon solar panels convert solar sun energy into electricity, which is stored in maintenance-free valve-sealed batteries or lithium batteries through the solar controller, and at night, the solar controller controls the discharge of the batteries for the LED lights to work. It will bring many benefits.

  • Energy saving

Convert solar energy into electricity to drive LED street lamps to work. Solar energy is inexhaustible.

  • Safety

Solar street lights are powered by 12-36V solar panels, which are within the safe voltage range and will not cause electric shock accidents to people, making them safer to use.

  • Flexible application

Off-grid solar street lights do not require grid power supply, and can operate autonomously as long as there is sunlight, which is very flexible, so they can use even in remote power-deficient areas.

  • Less investment

The solar street light system no need power supply equipment, can completely automated operation, no need personnel management, so low operation and maintenance costs.

Structure of Integrated Solar Streetlight

Structure of all in one solar led street light

1. LED Module

Using high-efficiency Philips Lumileds LED chips, the luminous efficiency is up to 205LM/W, the same luminous flux, the power can be reduced by 50%, which greatly reduces the overall cost.

2. Lithium Battery

Integrated solar street light usually use lithium battery as energy storage. Lithium battery are divided into ternary lithium batteries and lithium iron phosphate batteries (LiFePo4 batteries), Lithium battery is a key component in solar street lights, and the cost is also the highest.

3. Solar Controller

At present, most of the solar street lights on the market use PWM controllers, which are relatively cheap. With the continuous development of technology, more and more solar street lights use high-efficiency MPPT controllers, which are relatively expensive.

4. Sensor device

For integrated solar street lights, sensor devices generally include motion sensors, also known as microwave sensors, human body sensors, also known as infrared sensors, and radar sensors.

5. Solar Panels

Solar panels are divided into monocrystalline and polycrystalline solar panels. the conversion efficiency of monocrystalline is higher and the price is higher, polycrystalline solar panels is little cheaper but with low efficiency, now most integrated solar street light use mono solar panels.

People also ask

Solar street light is a kind of street lamp that uses crystalline silicon solar panels to generate electricity, maintenance-free valve-controlled sealed battery (colloidal battery) to store electric energy, ultra-bright LED lamps as light source and controlled by the intelligent charge and discharge controller to replace traditional public electric lighting.

According to different structural designs, solar street lights can be divided into split solar street lights, Semi-split solar street lights, and Integrated solar street lights.
Split solar street light means that the main components such as solar panels, solar batteries, solar controllers, and led lamps are completely independent.
Semi-split solar street light generally refers to the solar battery, the solar controller, and the led light is integrated. The solar battery uses lithium batteries and is small in size. It can be placed in the street light cavity together with the controller. The solar panel is separate, so it is called all in two solar street lights.
Integrated solar street light refers to the solar panel, battery, controller, and lamp are integrated, generally, the battery and controller are built-in, the battery panel is super on the back of the lamp, so it is also called “all in one solar street light”

Due to each city has its own sunshine condition, and customers have different working hours and rainy days on request, if you want to know the more exact configuration, please contact us for below questions:
1. What is the geographical location your solar LED street lighting system will be installed?
2. How many hours per night do the LED street light work?
3. How many days to backup in case of continuous rainy days?
4. Do you need to dim the LED street light (during the off-peak hours)?
5. Do you have any other requirements?

Related Projects

Series PV3 integrated solar street light in the farm in Malaysia

Series PV3 integrated solar street light for a farm in Malaysia

Series PV solar powered parking lot lights in amusement park in Thailand

Series PV solar powered parking lot lights in an amusement park in Thailand

Series PV2 solar street light with motion sensor for bus stop lighting in Serbia

Series PV2 solar street light with motion sensor for bus stop lighting in Serbia

Series PV2 all in one led solar street light in the mountain in Costa Rica

Series PV2 all in one led solar street light in the mountain in Costa Rica

Series PV2 All in one solar powered street lights for park lighting in UAE

Series PV2 All in one solar powered street lights for park lighting in UAE

Split solar street light

Series H 60 watt solar street light for highway lighting in Tunisia

Kmini led solar street lamp

Series Kmini led solar street lamp on Suburban highway in Tunisia

highway road lighting

Series H solar street lighting system for highway road lighting in Mexico

solar powered street lamp

Series Rifle solar powered street lamp for crossroads lighting in Bulgaria
