Series H5-C ALBA led street light
ALBA led street light is using PHILIPS LUMILEDS luminous source, providing excellent lumen output, long-lasting stability and splendid sight.High luminous efficiency and better service life.
Widely used in public street, commercial road, pathway, park, outdoor area lighting and etc.
Product Features
- Watts: 80-180w
- Modular design, easy for maintenance
- Light Efficiency up to 165lm/w
- Protection class I or II
- 10 /20KV surge protection, IP66&IK10
- Vairous optics for different applications
- Side entry or Vertical pole mounted
- CE, CB certified
- Smart Control: 1-10V dimming, DALI control, Photocell, Motion sensor, NEMA/Zhaga, Zigbee /Lora socket for smart control system or future updating
| Series No | Series H-5C |
| Power | 80W, 100W, 120W, 150W, 180W |
| Efficacy | 130-160lm/W |
| Input Voltage | 100-240/277 VAC, 50 / 60 Hz |
| Power Factor | >0.95 |
| Surge Protection | 10KV (Default) / 20KV (available on request) |
| IP Rating | IP66 |
| IK Rating | IK08 |
| CCT | 3000K, 4000K, 5000K, 5700K |
| CRI | Ra>70 (Default) / Ra>80 |
| Operating Temperature | -40°C to + 50°C |
| Beam Angle | Type I, Medium; Type II, Medium; Type III, Medium; Type V, Short; |
| Mounting Option | Suspending |
| Warranty | 7 Years |
| Certification | CB, CE, ROHS, LM79, LM80, ISO9001, ISO14001 |
| Control | 1-10V dimming, DALI control, Photocell, Motion sensor, NEMA/Zhaga, Zigbee /Lora socket for smart control system or future updating |
